BoxText
Version 1.0.0
This tool automatically draws a bounding rectangle (poly-line) around selected DBText and MText entities in a nanoCAD drawing. It accurately accounts for rotation, text height, and alignment, and can be used for visual labeling, annotation, or organizing text content on the drawing canvas.
Features
Supports both DBText and MText
Accurate bounding box with adjustable margin (offsetFactor)
Handles arbitrary text rotation (0–360°)
Honors text's normal vector and alignment
Works in model space or paper space
Automatically inherits layer, color, linetype, and lineweight of the text
